SPECIALTY HOSE

Specialty High Pressure Hose

Stainless Steel Braided Hose

Our stainless steel hose has excellent flexibility and is designed for confined potentially explosive atmospheres. This stainless steel braided hose ensures full surface conductivity and provides excellent resistance to paints, solvents and chemicals. In addition, we offer this stainless steel flexible hose among our other high pressure hose in customized lengths for any of your fluid dynamic needs.

Air Assisted Airless Welded Twin Hose

Equipped on an air assisted airless paint sprayer, our KMW23 high pressure hose series is a welded twin hose comprised of a 3/16” airless paint sprayer hose and a 1/4" pneumatic hose. Each hose is color coded for easy identification and can be used with your Graco air assisted airless spray gun and Wagner spray gun.

Teflon Core Hose

KM Coating offers a wide variety of specialty hoses designed for your airless paint sprayer or air assisted airless paint sprayer. Our PTFE hose with a thermoplastic cover is available in 1/8” ID to 1/2" ID and is rated up to 5,000 PSI. This Teflon core hose is able to be used in extremely high and low temperatures and chemically resistant of all common solvents including acids and bases. Teflon can be seen applying a large selection of spray coatings and is required for when harsh chemicals are being used.


TEFLON CORE - SERIES TC12, TC13, TC14, TC16 & TC18


The teflon hose series has excellent characteristics both in extreme high and low temperatures. It is chemically resistant of all common solvents including acids and bases. Easy to clean due to a non-contamination property. Has the lowest coefficient of friction of any polymer and resists deterioration.



Series: TC12 (1/8")
Maximum Working Pressure: 5,000 PSI
Minimum Burst Pressure: 20,000 PSI
Core: Teflon 140®
Braid: High Tensile Brass Plated Carbon Steel
Cover: Polyurethane

Color Length Part Number Fittings Price Qty Place Order
Black 5' TC12- 5FFSS 1/4" Females Stainless Steel
$60.00



Series: TC13 (3/16")
Maximum Working Pressure: 5,000 PSI
Minimum Burst Pressure: 20,000 PSI
Core: Teflon 140®
Braid: High Tensile Brass Plated Carbon Steel
Cover: Polyurethane

Color Length Part Number Fittings Price Qty Place Order
Black 5' TC13- 5FFSS 1/4" Females Stainless Steel
$60.00



Series: TC14 (1/4")
Maximum Working Pressure: 4,700 PSI
Minimum Burst Pressure: 18,850 PSI
Core: Teflon 140®
Braid: High Tensile Brass Plated Carbon Steel
Cover: Polyurethane

Color Length Part Number Fittings Price Qty Place Order
Black 5' TC14- 5FFSS 1/4" Females Stainless Steel
$69.25



Series: TC16 (3/8")
Maximum Working Pressure: 3,600 PSI
Minimum Burst Pressure: 14,400 PSI
Core: Teflon 140®
Braid: High Tensile Brass Plated Carbon Steel
Cover: Polyurethane

Color Length Part Number Fittings Price Qty Place Order
Black 5' TC16- 5FFSS 1/4" Females Stainless Steel
$98.50



Series: TC18 (1/2")
Maximum Working Pressure: 3,000 PSI
Minimum Burst Pressure: 12,000 PSI
Core: Teflon 140®
Braid: High Tensile Brass Plated Carbon Steel
Cover: Polyurethane

Color Length Part Number Fittings Price Qty Place Order
Black 5' TC18- 5FFSS 1/4" Females Stainless Steel
$104.65


AIR ASSISTED AIRLESS TWIN - SERIES KMW23


Twin hose assembly is welded together for Air Assisted Airless systems.  Color coded for easy identifiable hose.  This system is comprised of KX23 (3/16" Fluid Hose) and MO14 (1/4" Air Hose).



Color Length Part Number Fittings Price Qty Place Order
Blue 25' KMW23-25FBE 1/4" Females
$88.35

Blue 50' KMW23-50FBE 1/4" Females
$132.50


COMPLETE SURFACE CONDUCTIVE - SERIES SHA24


Designed for full surface conductivity for use in confined and potentially explosive atmospheres.





Series: SHA24 (1/4")
Maximum Working Pressure: 5,000 PSI
Minimum Burst Pressure: 20,000 PSI
Core: Polyamide
Braid: One Aramid, One Stainless Steel
Cover: None

Color Length Part Number Fittings Price Qty Place Order
N/A 60' SHA24-60FBE 1/4" Females
$253.35


DRAIN CLEANING – SERIES DP13


Designed to hydraulically clean drain pipes with sizes in excess of 1 1/4" regardless of pipe routing or configuration.





Series: DP13 (3/16")
Maximum Working Pressure: 4,000 PSI
Minimum Burst Pressure: 14,500 PSI
Core: Unplasticised Elastomer
Braid: High Tensile Carbon Steel
Cover: Polyurethane

Color Length Part Number Fittings Price Qty Place Order
Bronze 35' DP13-35 1/4" Male x 1/8" Male
$79.20

Bronze 75' DP13-75 1/4" Male x 1/8" Male
$130.00

Bronze 100' DP13-100 1/4" Male x 1/8" Male
$176.70

DRAIN CLEANING NOZZLES

Equip the DP13 series with either a high speed rotating nozzle or with a non rotating static nozzle.  Maximum Working Pressure is 4,000 PSI.

63-310

Part Number Main Description Price Qty Place Order
63-310 3 x 1 Static Nozzle / Seal
$17.95

63-317 3 x 1 + 1 Static Nozzle / Seal
$17.95

63-410 3 x 1 Rotating Nozzle / Seal
$70.00
