INDUSTRIAL

Flat Industrial TipThese industrial tips will apply a quality spray coating in a wide variety of different patterns and orifice combinations. These flat airless paint sprayer tips have a carbide mounted in a highly polished stainless steel jacket with a stainless steel insert pressed behind to increase flow and atomization of the spray coating. Due to the inexpensive nature of a flat high pressure spray nozzle, they are widely used in automatic and many manual applications.

These spray tips can be found applying a broad range of spray coating materials including stains, lacquers, oil based paints, latex, heavy paints and block fillers. There are over 300 different spray angle and orifice size combinations to get the exact spray tip needed in order to solve all your fluid handling requirements. If a super fine finish result is needed in applying the spray coating try one of our fine finish tips for precision spraying with the ultimate in high quality atomization. Additional airless paint sprayer tips are available upon request.

Part Number Size Main Description Price Qty Place Order
63-505-211 211 Degree: 20 / Orifice Size: 0.011 / Fan Pattern: 4-6 inches
$14.65

63-505-311 311 Degree: 30 / Orifice Size: 0.011 / Fan Pattern: 6-8 inches
$14.65

63-505-411 411 Degree: 40 / Orifice Size: 0.011 / Fan Pattern: 8-10 inches
$14.65

63-505-313 313 Degree: 30 / Orifice Size: 0.013 / Fan Pattern: 6-8 inches
$14.65

63-505-413 413 Degree: 40 / Orifice Size: 0.013 / Fan Pattern: 8-10 inches
$14.65

63-505-513 513 Degree: 50 / Orifice Size: 0.013 / Fan Pattern: 10-12 inches
$14.65

63-505-415 415 Degree: 40 / Orifice Size: 0.015 / Fan Pattern: 8-10 inches
$14.65

63-505-515 515 Degree: 50 / Orifice Size: 0.015 / Fan Pattern: 10-12 inches
$14.65

63-505-615 615 Degree: 60 / Orifice Size: 0.015 / Fan Pattern: 12-14 inches
$14.65

63-505-617 617 Degree: 60 / Orifice Size: 0.017 / Fan Pattern: 12-14 inches
$14.65



SPRAY TIP CLEANING NEEDLES

Triangular design enables it to clean any size tip helping to keep it at peak performance.

36-703

Part Number Main Description Price Qty Place Order
36-703 12 Needles for tips +.011
$14.50



UNIVERSAL PRE-ORIFICE

Used behind a flat tip to achieve a fine finish spraying application.  The shape of the pre-orifice will eliminate spitting effects at greatly reduced pressures.

63-003

Part Number Main Description Price Qty Place Order
63-003 Pre-orifice .012'' white
$11.60

63-004 Pre-orifice .016'' yellow
$11.60

63-005 Pre-orifice .019'' red
$11.60

63-007 Pre-orifice .026'' blue
$11.60

63-010 Pre-orifice .039'' black
$11.60
