FINE FINISH

Fine finish reversible airless paint sprayer tipsThese 5,000 PSI fine finish reversible airless paint sprayer tips will apply a quality spray coating in several different patterns and orifice combinations. These fine finish reversible spray tips incorporates a double orifice which atomizes the spray coating twice for an ultra fine finish result. There are over 15 different spray angle and orifice size combinations to get the exact tip needed in order to solve all your fluid dynamics requirements. If a higher pressure requirement is needed in applying the spray coating try the Speedy MKV fine finish spray tips.

These fine finish reversible airless paint spray tips will eliminate downtime by easily clearing a blockage away by spraying through the tip while it is in the reverse position. Even when administering the appropriate paint filters with your airless spray equipment, clogs will still occur at your spray tips which can be costly to shut down the entire system. In addition, reversible airless paint sprayer tips can be simply changed in seconds without having to remove the tip guard or adjusting any of your airless spray equipment. If a reversible spray tip system is required for your air assisted airless spray guns, try the TRIA Pro45, which eliminates bounce back of the spray coating and will adapt to several different spray guns.

Part Number Size Main Description Price Qty Place Order
88-201-208 208 Degree: 20 / Orifice Size: 0.008 / Fan Pattern: 4-6 inches
$29.95

88-201-308 308 Degree: 30 / Orifice Size: 0.008 / Fan Pattern: 6-8 inches
$29.95

88-201-408 408 Degree: 40 / Orifice Size: 0.008 / Fan Pattern: 8-10 inches
$29.95

88-201-210 210 Degree: 20 / Orifice Size: 0.010 / Fan Pattern: 4-6 inches
$29.95

88-201-310 310 Degree: 30 / Orifice Size: 0.010 / Fan Pattern: 6-8 inches
$29.95

88-201-410 410 Degree: 40 / Orifice Size: 0.010 / Fan Pattern: 8-10 inches
$29.95

88-201-510 510 Degree: 50 / Orifice Size: 0.010 / Fan Pattern: 10-12 inches
$29.95

88-201-212 212 Degree: 20 / Orifice Size: 0.012 / Fan Pattern: 4-6 inches
$29.95

88-201-312 312 Degree: 30 / Orifice Size: 0.012 / Fan Pattern: 6-8 inches
$29.95

88-201-412 412 Degree: 40 / Orifice Size: 0.012 / Fan Pattern: 8-10 inches
$29.95

88-201-512 512 Degree: 50 / Orifice Size: 0.012 / Fan Pattern: 10-12 inches
$29.95

88-201-612 612 Degree: 60 / Orifice Size: 0.012 / Fan Pattern: 12-14 inches
$29.95

88-201-214 214 Degree: 20 / Orifice Size: 0.014 / Fan Pattern: 4-6 inches
$29.95

88-201-314 314 Degree: 30 / Orifice Size: 0.014 / Fan Pattern: 6-8 inches
$29.95

88-201-414 414 Degree: 40 / Orifice Size: 0.014 / Fan Pattern: 8-10 inches
$29.95

88-201-514 514 Degree: 50 / Orifice Size: 0.014 / Fan Pattern: 10-12 inches
$29.95

88-201-614 614 Degree: 60 / Orifice Size: 0.014 / Fan Pattern: 12-14 inches
$29.95

STANDARD REVERSIBLE TIP BASE ASSEMBLY

Fits most major manufacturers airless spray guns.  Maximum Working Pressure is 5,000 PSI

88-200

Part Number Main Description Price Qty Place Order
88-200 7/8'' Thread Size
$21.00
