INDUSTRIAL

Industrial Reversible Paint Sprayer Tips

These 7,500 PSI industrial reversible airless paint sprayer tips will achieve an excellent finish in several different patterns and orifice combinations. Whether you require this industrial paint sprayer tip or need a fine finish version spray tip for your airless finishing equipment, you can find the exact reversible paint spray tips to solve all your fluid handling needs. There are over a 100 different spray angle and orifice size combinations to get the exact tip needed for the job.

These industrial reversible paint spray tips will eliminate downtime by easily clearing a blockage away by spraying through the tip while it is in the reverse position. Even when administering the appropriate paint filters with your airless spray equipment, clogs will still occur at your spray tips which can be costly to shut down the entire system. In addition, reversible airless paint sprayer tips can be simply changed in seconds without having to remove the tip guard or adjusting any of your finishing equipment. Additional paint sprayer tips available upon request and heavy duty industrial hose in stock.





IN MM   A°   .007 .009 .011 .013 .015 .017 .019 .021 .023 .025 .027 .029 .031 .033 .035
2-4 50-102 10° 107 109  111  113  115  117
4-6 102-152  20° 207  209  211  213  215  217 219 221 223 225
6-8 152-203 30° 307  309  311  313  315  317 319 321 323 325 327 329 331 333 335
8-10 203-254 40° 407  409  411  413  415 417  419 421 423 425 427 429 431 433 435
10-12 254-305  50°   509  511  513  515  517 519 521 523 525 527 529 531 533 535
12-14 305-356 60°   609  611  613 615  617 619 621 623 625 627 629 631 633 635
14-16 356-406 70°       713 715  717 719 721 723 725 727 729 731 733 735
16-18 406-457 80°        813 815  817  819 821 823 825 827 829 831 833 835
18-20 457-508 90°           917  919  921 923 925 927 929 931 933 935

Part Number Size Main Description Price Qty Place Order
88-207-211 211 Degree: 20 / Orifice Size: 0.011 / Fan Pattern: 4-6 inches
$38.00

88-207-313 313 Degree: 30 / Orifice Size: 0.013 / Fan Pattern: 6-8 inches
$38.00

88-207-413 413 Degree: 40 / Orifice Size: 0.013 / Fan Pattern: 8-10 inches
$38.00

88-207-415 415 Degree: 40 / Orifice Size: 0.015 / Fan Pattern: 8-10 inches
$38.00

88-207-515 515 Degree: 50 / Orifice Size: 0.015 / Fan Pattern: 10-12 inches
$38.00

88-207-517 517 Degree: 50 / Orifice Size: 0.017 / Fan Pattern: 10-12 inches
$38.00

88-207-619 619 Degree: 60 / Orifice Size: 0.019 / Fan Pattern: 12-14 inches
$38.00

INDUSTRIAL REVERSIBLE TIP BASE ASSEMBLY

Fits most major manufacturers airless spray guns.  Maximum Working Pressure is 7,500 PSI

88-207

Part Number Main Description Price Qty Place Order
88-207 7/8'' Thread Size
$28.00
