SPEEDY MKV

Speedy MKV Air Assisted Airless Spray Tips

The Speedy MKV guard design is the only reversible airless paint sprayer tip setup in the market that can be entirely dismantled for in-depth cleaning and maintenance to remain at peak performance. Whether you require our standard or fine finish pre-atomizer versions for your airless spray equipment, you can find the exact reversible paint spray tips to solve all your fluid handling requirements. With our wide selection of Speedy MKV reversible spray tips, you will always achieve a quality spray coating in various patterns and orifice combinations.

A primary advantage of reversible paint spray tips is the fact that they can eliminate downtime. Even if your finishing equipment is using the proper paint filters, clogs will still occur at your spray tips which can be costly to shut down. With reversible paint sprayer tips, you can easily clear a blockage simply by spraying through the tip while it is in the reverse position. In addition, reversible airless spray tips can be easily changed in seconds without having to remove the tip guard or adjusting any of your finishing equipment. Additional reversible paint spray tips available upon request and high pressure airless paint sprayer hose in stock.

Part Number Size Main Description Price Qty Place Order
88-501-409 409 Degree: 40 / Orifice Size: 0.009 / Fan Pattern: 8-10 inches
$28.00

88-501-311 311

Degree: 30 / Orifice Size: 0.011 / Fan Pattern: 6-8 inches

$28.00

88-501-411 411 Degree: 40 / Orifice Size: 0.011 / Fan Pattern: 8-10 inches
$28.00

88-501-511 511 Degree: 50 / Orifice Size: 0.011 / Fan Pattern: 10-12 inches
$28.00

88-501-213 213 Degree: 20 / Orifice Size: 0.013 / Fan Pattern: 4-6 inches
$28.00

88-501-313 313 Degree: 30 / Orifice Size: 0.013 / Fan Pattern: 6-8 inches
$28.00

88-501-413 413 Degree: 40 / Orifice Size: 0.013 / Fan Pattern: 8-10 inches
$28.00

88-501-513 513 Degree: 50 / Orifice Size: 0.013 / Fan Pattern: 10-12 inches
$28.00

88-501-613 613 Degree: 60 / Orifice Size: 0.013 / Fan Pattern: 12-14 inches
$28.00

88-501-315 315 Degree: 30 / Orifice Size: 0.015 / Fan Pattern: 6-8 inches
$28.00

88-501-415 415 Degree: 40 / Orifice Size: 0.015 / Fan Pattern: 8-10 inches
$28.00

88-501-515 515 Degree: 50 / Orifice Size: 0.015 / Fan Pattern: 10-12 inches
$28.00

88-501-615 615 Degree: 60 / Orifice Size: 0.015 / Fan Pattern: 12-14 inches
$28.00

88-501-417 417 Degree: 40 / Orifice Size: 0.017 / Fan Pattern: 8-10 inches
$28.00

88-501-517 517 Degree: 50 / Orifice Size: 0.017 / Fan Pattern: 10-12 inches
$28.00

88-501-419 419 Degree: 40 / Orifice Size: 0.019 / Fan Pattern: 8-10 inches
$28.00

88-501-519 519 Degree: 50 / Orifice Size: 0.019 / Fan Pattern: 10-12 inches
$28.00

88-501-619 619 Degree: 60 / Orifice Size: 0.019 / Fan Pattern: 12-14 inches
$28.00


Incorporates a double orifice which atomizes the coating twice for an ultra fine finish. Over 100 different spray angle / orifice size combinations to get the right tip for the job. Maximum Working Pressure is 7,500 PSI. Additional sizes available upon request.

Part Number Size Main Description Price Qty Place Order
88-502-104 104 Degree: 10 / Orifice Size: 0.004 / Fan Pattern: 2-4 inches
$39.75

88-502-206 206 Degree: 20 / Orifice Size: 0.006 / Fan Pattern: 4-6 inches
$39.75

88-502-208 208 Degree: 20 / Orifice Size: 0.008 / Fan Pattern: 4-6 inches
$39.75

88-502-308 308 Degree: 30 / Orifice Size: 0.008 / Fan Pattern: 6-8 inches
$39.75

88-502-408 408 Degree: 40 / Orifice Size: 0.008 / Fan Pattern: 8-10 inches
$39.75

88-502-508 508 Degree: 50 / Orifice Size: 0.008 / Fan Pattern: 10-12 inches
$39.75

88-502-310 310 Degree: 30 / Orifice Size: 0.010 / Fan Pattern: 6-8 inches
$39.75

88-502-410 410 Degree: 40 / Orifice Size: 0.010 / Fan Pattern: 8-10 inches
$39.75

88-502-412 412 Degree: 40 / Orifice Size: 0.012 / Fan Pattern: 8-10 inches
$39.75

88-502-414 414 Degree: 40 / Orifice Size: 0.014 / Fan Pattern: 8-10 inches
$39.75

SPEEDY MKV TIP BASE ASSEMBLY

Hand tighten to all popular spray guns.  Maximum Working Pressure is 7,500 PSI.

88-552

Part Number Main Description Price Qty Place Order
88-552 Base unit and seal 7/8 x 14
$22.25

88-554 Base unit and seal fits 3/4 x 20
$22.25

88-557 Base unit and seal fits 11/16 x 16
$22.25

88-505 MKV Reversible Tip Seal
$5.25
